NVR8-4100PN-V2
8MP 4CH PoE NVR embedded with check point protection, and NDAA compliance
Provision-ISR’s NVR8-4100PN-V2 offers a seamless solution tailored for mid-sized installations (up to 8 channels). Integrated with the Check Point Quantum IoT Nano agent, it ensures advanced threat prevention in real-time and safeguards against common attack vectors. With 4 PoE ports and compliance with NDAA requirements, this device provides all the essential features for a hassle-free CCTV project.
Video:
- Input: 4 Channel Support
- 4 Channel PoE / Standard Network Connection (Via 4 x RJ-45 / Network)
- Output: HDMI (4K, 1080P), VGA (1080P, 1280×1024, 1024×768)
Bandwidth:
- Incoming: 80Mbps
- Outgoing: 80Mbps
Decoding Support:
- H.265S/H.265+/H.265/H264
Analytics:
- Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, LPR, Thermal
Recording:
- 4CH 8MP Real-Time
- FPS: 100 (PAL) / 120 (NTSC)
Playback:
- Local: 4Ch Simultaneously
- Remote: 4Ch Simultaneously
Audio:
- Input: 1CH + IPC Inputs
- Output: 1CH + IPC Output
- 2 Way Audio
Alarm:
- Input: Based on IPC only
- Output: Based on IPC only
Storage:
- 1 x SATA (Up to 10TB each)
USB Port:
- 2 USB 2.0 Port
Network:
- 1 x RJ-45: 10/100/1000Mbps Each
Remarks:
- The following features are based on firmware v1.4.10 and are subject to firmware version changes.
