HiKvision Hybrid SAN
DS-AT1000S/360 HIKVISION STORAGE Special Order Item Hikvision 400ch Hybrid SAN 360TB storage, iRAID technology,
| Gateway | Price |
|---|---|
| PayPal | $15,093.00 |
د.إ55,900.00
Compare
EOL
16-slot Cost-efficient Super Capacity Storage
- 15*20 TB IoT SMR enterprise HDD
- IoT fully sealed helium HDD technology
- Surveillance-specialized direct storage (Direct Streaming mode)
- Highly cost efficient, safe and reliable
- Energy saving and space saving
- Easy operation and maintenance
- SMR HDD providing 5-year warranty
- Cache12 GB, extendable to 32 GB
- Processor64-bit multi-core processor
- Storage Management
- Disk ManagementDisk detection, pre-alarm, and repair
- Logical Volume ManagementRecording volume management
- Recording Management
- Recording ModeContinuous recording, manual recording, and alarm recording
- Video ProtectionVideo lock, video loss alarm
- Searching ModeLog in storage system to search, play, and download videos. Support searching videos by time, event type, and smart information
- Downloading ModeLog in storage system to search, play, and download videos. Support searching videos by time, event type, and smart information
- Network
- ProtocolRTSP;ONVIF;HKSDK
- Device Maintenance
- Management ModeGUI based on web, serial port CLI, platform
- Alarm ModeAudio, indicator, GUI
- Storage
- HDD Slot16
- Interface/CapacitySATA, Up to 20TB
- RAIDRAID5, RAID6, iRAID
- Performance
- Video Performance256
- Picture Performance50
- Direct Streaming Mode: Video (2 Mbps) + Picture256-ch
- General
- Power Supply100 to 127 VAC or 200 to 240 VAC/47 to 63Hz, redundant power supply
- Consumption (With HDDs)≤ 255 W
- Environment TemperatureWorking: +5 °C to +40 °C (41 °F to 104 °F) Storing: -20 °C to +70 °C (-4 °F to +158 °F)
- Environment HumidityWorking: 20% to 80%RH (non-condensing/frozen) Storing: 5% to 90%RH (non-condensing/frozen)
- Dimension (W × H × D)486 x 535 x 134 mm (19.2 x 21.1 x 5.3 in)
- Weight (Without HDDs)≤20kg (44.1 lb)
- External Interface
- USB2, USB 3.0
- Data Network Interface3, 1000 Mbps Ethernet interface
- MiniSAS Interface2
- COM1, RS-232
- Management Network Interface1, 1000 Mbps Ethernet interface
- HDD
- HDD ModelHikvision,HK7220AH,20T
